PRODUCTS
Strengths
PRECISE AND GENTLE
CONTACTING
COMPREHENSIVE TESTS
SIMPLE AND USER-
FRIENDLY SOFTWARE
Flying Probe Tester
- Stand-alone type / Inline type
- Single sided
APT-2400F
Entry model with four probes for single-sided test
2400F supports the testing of high-density mounted boards, boasting industry-leading probing accuracy, and achieves highly reliable electrical tests. Capable of ultra-high-speed tests at a speed of 0.02 seconds/step.
- Stand-alone type / Inline type
- Single sided
- Large size
APT-2400F-SL
Four-probe single-sided test for large printed circuit boards
2400FD-SL supports the testing of large-sized mounted boards such as power supply boards and probe cards. Capable of testing boards up to 985 x 610mm. Achieves both highly accurate positioning and high-speed test.
- Stand-alone type / Inline type
- Double sided
APT-2600FD
Flagship model with six probes for double-sided test
2600FD is equipped with four probes on the top side and two probes on the bottom side of the board. Each probe moves freely at high speed, achieving world-class test speed through simultaneous dual-side contact.
- Stand-alone type / Inline type
- Double sided
- Large size
APT-2600FD-SL
Six-probe flagship model for double-sided test of large circuit boards
2600FD-SL maintains the basic performance of the APT-2600FD while increasing size, realizing an expanded test range and reduced time.
- Stand-alone type / Inline type
- Single sided
APT-1400F
Entry model with four probes for single-sided test
APT-1400F is a standard model which is capable of testing all types of assembled printed circuit boards.
- Stand-alone type / Inline type
- Single sided
- Large size
APT-1400F-SL
Four-probe single-sided test for large printed circuit boards
APT-1400F-SL is for the test of large assembled printed circuit boards.
- Stand-alone type / Inline type
- Double sided
APT-1600FD
Flagship model with six probes for double-sided test
Four probes are equipped above the top surface and two under the bottom surface of the circuit board.
- Stand-alone type / Inline type
- Double sided
- Large size
APT-1600FD-SL
Six-probe flagship model for double-sided test of large circuit boards
APT-1600FD-SL can test a large, long circuit boards of up to 985×610 mm without losing the performance.
Find Us By Applications
Semiconductor manufacturing equipment
Benefits
Flying probe testers, capable of 0.15mm pitch probing, can contact almost any location even without a test point and perform very high testing coverage.
EMS Companies
Benefits
Takaya flying probe testers can immediately adapt to specification changes, enabling high-quality production in even from the prototype level. They establish and verify mass production data such as solder printing and appropriate temperature control for reflow. They check for reworking mistakes such as retrofitting and replacement of components.
Communications, infrastructure and servers
Benefits
Suitable for testing high-mix and low-volume circuit boards as they eliminate jig costs and reduce lead time of products. Appropriate test settings on each component can provide high quality test for various printed circuit boards which prevents the defects to be occurred.
Medical equipment
Benefits
Flying probe tester can detect defects which cannot be detected by AOI and expect more from using them together. By making use of the best features of each methodology, false information can be eliminated, which results in higher test capability and test speed.
Power generation and power systems
Benefits
We can electrically test manually-inserted components related to power lines that are difficult to detect by image test such as misdistributions, bridges, short circuits and polarities. Takaya flying probe testers prevent the destruction of components and circuit boards when powering on, reducing wastage of circuit boards.
Consumer products
Benefits
Chip components are temporarily mounted on a bare board with double-sided tape, and sampling test (ensuring that the number of components is correct) is performed by contacting the electrodes of the chip components. Handwork and visual checks can be performed more accurately within a short time.
Automotive
Benefits
Using the flying probe tester enables defects to be found easily. It significantly shortens repair time and reduces wastage of circuit boards.
Aviation and Aerospace
Benefits
Once created the test program, the tester is immediately ready to test even from the prototype level to find defects which cannot be detected by AOI, XOI and functional test.
Lighting
Benefits
Automatic test using a color sensor eliminates burden on workers. It provides a stable test with clear criteria based on numerical comparison.
- Stand-alone type / Inline type
- Single sided
APT-2400F
Entry model with four probes for single-sided test
2400F supports the testing of high-density mounted boards, boasting industry-leading probing accuracy, and achieves highly reliable electrical tests. Capable of ultra-high-speed tests at a speed of 0.02 seconds/step.
- Stand-alone type / Inline type
- Single sided
- Large size
APT-2400F-SL
Four-probe single-sided test for large printed circuit boards
2400FD-SL supports the testing of large-sized mounted boards such as power supply boards and probe cards. Capable of testing boards up to 985 x 610mm. Achieves both highly accurate positioning and high-speed test.
- Stand-alone type / Inline type
- Double sided
APT-2600FD
Flagship model with six probes for double-sided test
2600FD is equipped with four probes on the top side and two probes on the bottom side of the board. Each probe moves freely at high speed, achieving world-class test speed through simultaneous dual-side contact.
- Stand-alone type / Inline type
- Double sided
- Large size
APT-2600FD-SL
Six-probe flagship model for double-sided test of large circuit boards
2600FD-SL maintains the basic performance of the APT-2600FD while increasing size, realizing an expanded test range and reduced time.
- Stand-alone type / Inline type
- Single sided
APT-1400F
Entry model with four probes for single-sided test
APT-1400F is a standard model which is capable of testing all types of assembled printed circuit boards.
- Stand-alone type / Inline type
- Single sided
- Large size
APT-1400F-SL
Four-probe single-sided test for large printed circuit boards
APT-1400F-SL is for the test of large assembled printed circuit boards.
- Stand-alone type / Inline type
- Double sided
APT-1600FD
Flagship model with six probes for double-sided test
Four probes are equipped above the top surface and two under the bottom surface of the circuit board.
- Stand-alone type / Inline type
- Double sided
- Large size
APT-1600FD-SL
Six-probe flagship model for double-sided test of large circuit boards
APT-1600FD-SL can test a large, long circuit boards of up to 985×610 mm without losing the performance.
For detail information,
please contact our certified partners in your region.
