APPLICATION SOFTWARE

Takaya original software allows you to import circuit board design CAD data (ODB++ format) and directly create inspection programs.

Recommend

Customers who require electrical test of high-mix and low-volume circuit boards

Customers who would like to reduce the cost/time required for creating test programs and improve efficiency

Customers who would like to perform electrical test but lack of experience in circuit design

Contribute to reducing operator workload and increasing inspection efficiency with intuitive and easy-to-understand operations.

ODB++

About

ODB++ is Takaya original software that allows you to import CAD data (ODB++ format) to create test programs directly.

Features

01Direct Conversion To Test Programs

Extracts component/net information straight from ODB++ data and converts it directly into a test program.
This eliminates the need to edit Gerber data or manually input net information, thus significantly reducing work time.

ODB++ conversion method

Traditional conversion method

02Visualization Of Circuit Elements

Visualization of circuit elements allows you to identify defects easily.

03Automatic Extraction/Fixing Of Modification Areas

When making design changes, CAD data will automatically be reloaded to detect the location of changes and make the modifications, making it easy to revise the program.

Benefits

01Shorter Test Times

Combination measurement significantly reduces the number of contacts.

02Accurate And Stable Test

Determines the best contact points on the same network and automatically selects priority contacts.

03Expanded Test Area

Even if the pad size is too small to contact both ends of the component, it can be tested from another point on the same net.

What is ODB++？

ODB++ (Open Data Base) is one of the data formats generated by CAD for circuit board design.

It contains all the information needed to design a circuit board and for communication with mounting contractors, and itself can be used to manufacture the circuit board. With ODB++, failures due to missing information or misrecognition will not occur.

Since the specifications of ODB++ are open to the public and can be used freely, many circuit board manufacturers have adopted it.

Supply chain using ODB++

traditional supply chain

  • Stand-alone type / Inline type
  • Single sided

APT-1400F

Entry model with four probes for single-sided test

APT-1400F is capable of testing all types of assembled printed circuit boards, including those in vehicles, aircraft and medical equipment with ultra-high-speed test at a maximum speed of 0.02 seconds per step.

READ MORE

  • Stand-alone type / Inline type
  • Single sided
  • Large size

APT-1400F-SL

Four-probe single-sided test for large printed circuit boards

APT-1400F-SL is for the test of large assembled printed circuit boards with applications such as power generation, probe cards and 5G servers. Achieves both highly accurate positioning and high-speed test.

READ MORE

  • Stand-alone type / Inline type
  • Double sided

APT-1600FD

Flagship model with six probes for double-sided test

Four probes are located above the top surface and two under the bottom surface of the circuit board. Each probe moves independently at high speed to achieve the world’s fastest test speed.

READ MORE

  • Stand-alone type / Inline type
  • Double sided
  • Large size

APT-1600FD-SL

Six-probe flagship model for double-sided test of large circuit boards

APT-1600FD-SL can test a large, long circuit boards of up to 985×610 mm without losing the performance. Combination test using six probes further expands test capabilities and shortens the time.

READ MORE
